The ProX KT-F34SQ328 ProX KT Series F34 Aluminum Truss | 1.5mm Wall is built to the highest standards of safety and performance. It’s a rugged yet lightweight trussing solution and is an Economy Light-Structural trussing system for light-duty use for trade show booths, DJ booths, DJ Totems, architectural non-loadbearing designs, and much more. The ProX KT-F34SQ328 is particularly well suited for trade shows and light-duty construction of display systems, as well as event technology and as a support system for lighter lighting fixtures. Due to its design appearance combined with a lower cost, it provides the ability for reduced load capacity designs with a standard truss appearance. This system is ideally suited from a simple exhibition display up to a complex trade show booth.
Fits: Compatible in SIZE ONLY w/most major brands F34 Box Square Truss with conical connectors.
Product Specification:
KT-F34 SERIES DIMENSIONS:
Width: 11.42in / 290mm
Height: 11.42in / 290mm
Main Tube: 2in / 50mm
Wall Thickness: .06in / 1.5mm
Braces: .63in / 16mm
Dimensions: 39.36″L x 11.42″W x 11.42″H
Weight: 11.00 lbs
Shipping Dimensions: 41.00″L x 12.00″D x 12.00″H
Shipping Weight: 12.50 lbs
Load Bearing Chart
