ETC IRFPZ-50/80-120C-DMX Irideon FPZ 5000 K (80+ CRI) Fixture, with DMX Control, Canopy Mount, Black
Sale!

ETC IRFPZ-50/80-120C-DMX Irideon FPZ 5000 K (80+ CRI) Fixture, with DMX Control, Canopy Mount, Black

Original price was: $852.00.Current price is: $170.40.

SKU: IRFPZ-50\/80-120C-DMX Category: Tag:

Product Description

ETC IRFPZ-50/80-120C-DMX Irideon FPZ 5000 K (80+ CRI) Fixture, with DMX Control, Canopy Mount, Black

Irideon FPZ pairs the best of the Source Four Mini LED platform with exceptional output and a sleek industrial design to light your space with elegance and subtlety. Available for use with our DataTrack system, the feature-rich design is perfect for museums, lobbies, and retail environments.

Truly a Source Four fixture at heart, Irideon FPZ boasts its own set of enhancements such as lockable 3-plane shutters, zoom optics, and the ability to dim using either DMX or a local dimming knob located on the DataTrack adapter. But the beam is still everything you expect and more; Irideon FPZ puts out over 800 lumens, 33% brighter than Source Four Mini LED and every bit as pleasing to the eye with a wide selection of color temperatures.

FPZ DataTrack model

  • Designed to operate with ETC’s DataTrack distribution system
  • Two track options available:
    • DataTrack 120V two-circuit
    • Eutrac 230V three-circuit with data
  • Color-matched adapter with fully integrated driver
  • DMX or locally dimmed

FPZ Portable model

  • Color matched, medium c-clamp mounting for pipe-mount installations.
  • DMX in and thru via RJ45 ports on the included driver box
  • Available accessory kit for Unistrut mounting
  • 6’ power cable with NEMA 5-15P connector included
  • DMX or locally dimmed

FPZ Canopy model

  • Available as DMX or DALI or 0-10V
  • The DMX option can be locally dimmed
  • Canopy mounted with color-matched mounting plate
  • 277V options available
More than you expect
  • Over 800 lumens, 33% brighter than Source Four Mini LED
  • Lockable, 3-plane shutters
  • Zoom optics
  • Dimming to less than 1% of maximum output
The Source Four touch
  • Exceptional optics, beam, and brightness
  • Rotating barrel, pattern slot, and integrated media frame
  • Backed by ETC’s award-winning service and support
Tailored to your needs
  • Offered in black, white, silver, or custom colors
  • Available in 2700 K Gallery (90+CRI), 3000 K, 3000 K Gallery (90+ CRI), 4000 K, and 5000 K LED color temperatures

FPZ gives you the versatility you need to create the beautiful light you want from an integrated, unassuming design that won’t dominate your space.

General Information

The Irideon FPZ is an LED framing projector with zoom optics that provides the highest quality beam, making it ideal for museums, lobbies, retail stores and more. A range of color temperature options from 2700 K to 5000 K make the FPZ well suited for any application, while track, canopy and portable mounting options provide the flexibility to meet any installation’s needs. The superior quality zoom optics paired with three-plane shutters and a rotating barrel enable the FPZ to create a sharp or soft focused light in any shape you need. And when used with either glass or metal gobos, logos and designs look sharp and distinctive.

APPLICATIONS:

• Museums• Retail stores• Restaurants• Hospitality/Lobbies• Theatres

FEATURES:

• Rugged fixture body• 25–50 degree zoom optics• Uniquely efficient optical system• Three-plane shutters• DMX control with built-in intensity trim feature• DALI or 0–10 V control option availabe for canopy version• Dimming to less than 1% of maximum output• Available in black, white and silver – Custom paint colors available; contact ETC

POWER INPUT OPTIONS

MODEL 100-120 VAC 100-277 VAC 230-240 VAC PORTABLE X   X TRACK X   X CANOPY – DMX   X   CANOPY – 0 = 10 V   X   CANOPY – DALI   X

Irideon FPZ

MODEL COLOR TEMP CRI VOLTAGE MOUNTING CONTROL COLOR
IRFPZ – Irideon FPZ

27 – 2700 K

30 – 3000 K

40 – 4000 K

50 – 5000 K

80 – Standard

90 – Gallery

120 – 120 V

230 – 230 V

277 – 100–277 V

T – Track

C – Canopy

P – Portable (Edison Plug)

PU – Portable (UK 13A Plug)

PE – Portable (EU Schuko Plug)

X – DMX

D – DALI

010 – 0–10 V

BLANK – Black

1 – White

5 – Silver

8 – Custom

*(277 only available with Canopy option)*

*(Gallery only available with 2700 K and 3000 K options. Standard only available in 3000 K, 4000 K and 5000 K options)*

*(DALI and 0–10 V only available with Canopy option)*

CONTROL OPTIONS TRACK CANOPY PORTABLE
Line Dimming
DMX Dimming ✓ ✓ ✓
DALI Dimming   ✓
0-10v Dimming   ✓
